Sanyo PLC-XP200L Service Manual

-80-
Chassis Description
Error Error Code
Error Infomation
(See Powe Failure Detection System)
Error Code
Error Infomation
(See Powe Failure Detection System)
Normal 0 -
Power Failure
1000
DVI, 3.3V
1021
AV, S-6V
1001
AD, 3.3V
1022
YE, 25V
1002
AD, 1.8V
1023
FN904, 13V
1003
KS, 3.3V
1024
FN902, 13V
1004
KS, 2.5V
1025
FN901, 13V
1005
KS, 1.8V
1026
FN908, 13V
1006
FPGA, 3.3V
1027
FN905&6 13V
1007
FPGA, 2.5V
1028
FN903, 13V
1008
FPGA, 1.2V
1029
FN907, 13V
1009
GAMMA, 3.3V
1030
AUDIO, 9V
1010
GAMMA, 2.5V
1031
SWFPGA, 1.2V
1011
GAMMA, 1.8V
1032
MAIN, S5V
1012
SH, 3.3V
1033
MAIN, 5V
1013
GAMMA, 15.5V
1034
FILTER, DET
1014
PJNET, S5V
1035
MOTOR, TIMEOUT
1015
LENS, 9V
1036
PRESS, ERROR
1016
LENS, 15V
1017
MAIN, 6V
1018
MAIN, 3.3V
1019
FILTER, 12V
1020
AV, S5V
Temperature Error
2000
Sensor A detects abnormal temperature. (IC1816)
2001
Sensor A fails measurement. (IC1816)
2100
Sensor B detects abnormal temperature. (IC1814)
2101
Sensor B fails measurement. (IC1814)
2102
Sensors B-A temperature error.
2200 Sensor C detects abnormal temperature. (IC1692)
2201 Sensor C fails measurement. (IC1692)
2202
Sensors C-A temperature error.
Lamp Error
3000 Lamp1 fails on
3001 Lamp1 goes out
3002
Communication Error on Lamp1
System Error
4000
FPGASW, CONFIG
4001
FPGAFINE, CONFIG
Shutter Error 5000
SHUTTER, ERROR
Filter Error 6000 Filter clogged
Error History Log
This projector provides the error history log function. To
check the logs, you need to enter the service mode and
select Group No. "220" and Item No. "0" to "49". The error
code is displayed on the Data column. The description of
the error code is listed on the table below.
* How to enter the service mode and select the group, item
and data value, see "Service Adjustment Menu Opera-
tion".
Group
No.
Item
No.
Data
(Error Code)
220 0
1
2
3
:
:
49
✻
<- Latest Error
✻
✻
✻
:
:
✻
How to reset the Error History Log
1. Enter the Service Mode, and select Group No. "220" and Item No. "50".
2 The history log will be reset when the Data Value is set to "10". The value automatically returns to "0".
* How to enter the service mode and select the group, item and data value, see "Service Adjustment Menu Operation".

Sanyo PLC-XP200L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Bundled software	User Manual (CD ROM)
I/O ports	DVI-D (digital/HDCP) D-Sub15 (RGB/SCART-RGB) 5 x BNC (RGBHV/Composite/Y-Pb/Cb-Pr/Cr) 3 x RCA (Video/Y-Pb/Cb-Pr/Cr) Mini DIN 4 (S-Video) 3.5 mm Stereo Jack D-Sub15 D-Sub9 (RS232) 3.5 mm Stereo Jack (cable remote control) USB type B
Compatibility	UXGA SXGA SXGA+ WXGA XGA S-VGA VGA Mac
Dimensions (WxDxH)	370 x 440 x 187 mm
Power requirements	100 - 240 V
Power consumption (standby)	24.5 W
Power consumption (typical)	499 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Placement	Ceiling

Weight and Dimensions

Weight	11400 g
Package weight	15900 g
