Sanyo PLC-XP200L Service Manual

-63-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
16 Ye Auto : AV Standard : LVL_USE x0.01 1 - 999 90
17 Ye Auto : AV Standard : W_SXY_0 x0.001 0 - 999 310
18 Ye Auto : AV Standard : W_SXY_1 x0.001 0 - 999 335
19 Ye Auto : AV Standard : B_SXY_0 x0.001 0 - 999 310
20 Ye Auto : AV Standard : B_SXY_1 x0.001 0 - 999 335
21
Ye Auto : AV Standard :
LIMIT_CONTRAST
100 - 5000 1500
22
Ye Auto : AV Standard :
CAL_CONT
RESULT CONTRAST (Read only)
23
Ye Auto : AV Standard :
CONT_USE
Used Rate at Black Balance (x0.001) 100 - 5000 500
24 Ye Auto : AV Cinema : LVL_USE x0.01 1 - 999 85
25 Ye Auto : AV Cinema : W_SXY_0 x0.001 0 - 999 315
26 Ye Auto : AV Cinema : W_SXY_1 x0.001 0 - 999 328
27 Ye Auto : AV Cinema : B_SXY_0 x0.001 0 - 999 315
28 Ye Auto : AV Cinema : B_SXY_1 x0.001 0 - 999 328
29
Ye Auto : AV Cinema :
LIMIT_CONTRAST
100 - 5000 1500
30
Ye Auto : AV Cinema :
CAL_CONT
RESULT CONTRAST (Read only)
31
Ye Auto : AV Cinema :
CONT_USE
Used Rate at Black Balance (x0.001) 100 - 5000 500
32 Ye OFF : PC Standard : LVL_USE x0.01 1 - 999 90
33 Ye OFF : PC Standard : W_SXY_0 x0.001 0 - 999 290
34 Ye OFF : PC Standard : W_SXY_1 x0.001 0 - 999 315
35 Ye OFF : PC Standard : B_SXY_0 x0.001 0 - 999 0
36 Ye OFF : PC Standard : B_SXY_1 x0.001 0 - 999 0
37
Ye OFF : PC Standard :
LIMIT_CONTRAST
100 - 5000 5000
38
Ye OFF : PC Standard :
CAL_CONT
RESULT CONTRAST (Read only)
39
Ye OFF : PC Standard :
CONT_USE
Used Rate at Black Balance (x0.001) 100 -5000 500
40 Ye OFF : PC Real : LVL_USE x0.01 1 - 999 75
41 Ye OFF : PC Real : W_SXY_0 x0.001 0 - 999 295
42 Ye OFF : PC Real : W_SXY_1 x0.001 0 - 999 320
43 Ye OFF : PC Real : B_SXY_0 x0.001 0 - 999 295
44 Ye OFF : PC Real : B_SXY_1 x0.001 0 - 999 320
45
Ye OFF : PC Real :
LIMIT_CONTRAST
100 - 5000 900
46 Ye OFF : PC Real : CAL_CONT RESULT CONTRAST (Read only)
47 Ye OFF : PC Real : CONT_USE Used Rate at Black Balance (x0.001) 100 -5000 500
48 Ye OFF : AV Standard : LVL_USE x0.01 1 - 999 80
49 Ye OFF : AV Standard : W_SXY_0 x0.001 0 - 999 290
50 Ye OFF : AV Standard : W_SXY_1 x0.001 0 - 999 315
51 Ye OFF : AV Standard : B_SXY_0 x0.001 0 - 999 290
52 Ye OFF : AV Standard : B_SXY_1 x0.001 0 - 999 315
53
Ye OFF : AV Standard :
LIMIT_CONTRAST
100 - 5000 1300
54
Ye OFF : AV Standard :
CAL_CONT
RESULT CONTRAST (Read only)
55
Ye OFF : AV Standard :
CONT_USE
Used Rate at Black Balance (x0.001) 100 -5000 500
56 Ye OFF : AV Cinema : LVL_USE x0.01 1 - 999 75
57 Ye OFF : AV Cinema : W_SXY_0 x0.001 0 - 999 313
58 Ye OFF : AV Cinema : W_SXY_1 x0.001 0 - 999 329
59 Ye OFF : AV Cinema : B_SXY_0 x0.001 0 - 999 313
60 Ye OFF : AV Cinema : B_SXY_1 x0.001 0 - 999 329
61
Ye OFF : AV Cinema :
LIMIT_CONTRAST
100 - 5000 1300
62
Ye OFF : AV Cinema :
CAL_CONT
RESULT CONTRAST (Read only)
63
Ye OFF : AV Cinema :
CONT_USE
Used Rate at Black Balance (x0.001) 100 -5000 500
64 Auto Gamma CALC Auto Gamma Adj Starts when the Value is set to 10. 0 - 10 0 * White balance adj.
65 Auto Gamma CALC MODE Gamma Curve Algorithm Select 0 - 1 0
983 DAC Adj Pamameter DAC Adj Parameter Setting
0 Green ColorA X x0.001(0.000~1.000) 0 - 1000 323
1 Green ColorA Y x0.001(0.000~1.000) 0 - 1000 655
2 Green ColorB X x0.001(0.000~1.000) 0 - 1000 323
3 Green ColorB Y x0.001(0.000~1.000) 0 - 1000 655
4 Calcurated G Color X x0.001(0.000~1.000) (Read only) 0 - 1000

Sanyo PLC-XP200L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Bundled software	User Manual (CD ROM)
I/O ports	DVI-D (digital/HDCP) D-Sub15 (RGB/SCART-RGB) 5 x BNC (RGBHV/Composite/Y-Pb/Cb-Pr/Cr) 3 x RCA (Video/Y-Pb/Cb-Pr/Cr) Mini DIN 4 (S-Video) 3.5 mm Stereo Jack D-Sub15 D-Sub9 (RS232) 3.5 mm Stereo Jack (cable remote control) USB type B
Compatibility	UXGA SXGA SXGA+ WXGA XGA S-VGA VGA Mac
Dimensions (WxDxH)	370 x 440 x 187 mm
Power requirements	100 - 240 V
Power consumption (standby)	24.5 W
Power consumption (typical)	499 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Placement	Ceiling

Weight and Dimensions

Weight	11400 g
Package weight	15900 g
