Appendix C Setpoint Triggers and Actions
124 Series PM172 Powermeters
Display Code Designation Description
ArHi.q.E HI kvar EXP AVR High total kvar export
ArHi. S HI kVA AVR High total kVA
ArPF.LG HI PF LAG AVR Low total PF Lag
ArPF.Ld HI PF LEAD AVR Low total PF Lead
1-Sec Auxiliary Values
ArnEU.C HI In AVR High neutral current
ArHi.Fr HI FREQ RT High frequency
ArLo.Fr LO FREQ RT Low frequency
ArHU.Ub
HI V UNB% RT
1
High voltage unbalance
ArHC.Ub HI I UNB% RT High current unbalance
Present Demands
Hi d.U1
HI V1/12 DMD
1
High V1/V12 Volt demand
Hi d.U2
HI V2/23 DMD
1
High V2/V23 Volt demand
Hi d.U3
HI V3/31 DMD
1
High V3/V31 Volt demand
Hi d.C1 HI I1 DMD High I1 Ampere demand
Hi d.C2 HI I2 DMD High I2 Ampere demand
Hi d.C3 HI I3 DMD High I3 Ampere demand
Hi d.P.i HI kW IMP BD High block kW import demand
Hi d.P.E HI kW EXP BD High block kW export demand
Hi d.q.i HI kvar IMP BD High block kvar import demand
Hi d.q.i HI kvar EXP BD High block kvar export demand
Hi d. S HI kVA BD High block kVA demand
HiSd.P.i HI kW IMP SD High sliding window kW import demand
HiSd.P.E HI kW EXP SD High sliding window kW export demand
HiSd.q.i HI kvar IMP SD High sliding window kvar import demand
HiSd.q.i HI kvar EXP SD High sliding window kvar export demand
HiSd. S HI kVA SD High sliding window kVA demand
HiAd.P.i HI kW IMP ACC DMD High accumulated kW import demand
HiAd.P.E HI kW EXP ACC DMD High accumulated kW export demand
HiAd.q.i HI kvar IMP ACC DMD High accumulated kvar import demand
HiAd.q.i HI kvar EXP ACC DMD High accumulated kvar export demand
HiAd. S HI kVA ACC DMD High accumulated kVA demand
HiPd.P.i HI kW IMP PRD DMD High predicted kW import demand
HiPd.P.E HI kW EXP PRD DMD High predicted kW export demand
HiPd.q.i HI kvar IMP PRD DMD High predicted kvar import demand
HiPd.q.i HI kvar EXP PRD DMD High predicted kvar export demand
HiPd. S HI kVA PRD DMD High predicted kVA demand
Pulse Inputs
PLS.In.1 PULSE INPUT #1 Pulse input #1
PLS.In.2 PULSE INPUT #2 Pulse input #2
Internal Events
E
PLS.Ac.i kWh IMP PULSE kWh import pulse
PLS.Ac.E kWh EXP PULSE kWh export pulse
PLS.rE.i kvarh IMP PULSE kvarh import pulse
PLS.rE.E kvarh EXP PULSE kvarh export pulse
PLS.rE.t kvarh TOT PULSE kvarh total pulse
PLS.AP.t kVAh TOT PULSE kVAh total pulse
PLS.P.dn START DMD INT Start new demand interval
PLS.S.dn START SD INT Start new sliding window demand interval
PLS.A.dn START AMP DMD INT Start new volt/ampere demand interval
PLS.trF START TARIFF INT Start new tariff interval
Pulse Counters
Cnt.1 HI COUNTER #1 High pulse counter #1
Cnt.2 HI COUNTER #2 High pulse counter #2
Cnt.3 HI COUNTER #3 High pulse counter #3
Cnt.4 HI COUNTER #4 High pulse counter #4
Timers
E
t-r.1 TIMER #1 Timer #1
t-r.2 TIMER #2 Timer #2
TOU Parameters
E
trF TOU TARIFF TOU Tariff
PrF TOU PROFILE TOU Profile
Time and Date Parameters
E
U.dAY DAY OF WEEK Day of week
YEAr YEAR Year
