SATO CL4NX Programming Reference

319
[ESC+QV] QR code version
ESC QV ParameterHexadecimal code
<1B>
16
<51>
16
<56>
16
aa
Initial value aa=00
When the power is OFF The set parameter is not maintained.
Valid range within items The set parameter is in effect until a new specification is
made.
Valid range and term of
command
Valid range between items The set parameter becomes a default value in the next
item <A>.
[Function]
Specifying any QR code version can print the code with fixed cell size.
When not specified, it becomes the auto setting.
[Format]
<QV>aa
• Parameter
a [Version number]
Valid range : 00 to 40
(Specifying this range does not become a parameter error.
An error may arise for some QR code types, while analyzing the image.)
Print valid MODE1 : 00 to 14 (00: Auto setting)
MODE2 : 00 to 40 (00: Auto setting)
MicroQR : 00 to 04 (M1 to M4) (00: Auto setting)
[Coding Example 1]
MODEL 1, Error correction: H, Cell size font: 05, Manual setting, Normal mode, Version 14
<A>
<V>100<H>100 <2D31>,H,05,0,0
<QV>14
<DN>0011,0123456789X
<Q>1
<Z>
[Coding Example 2]
MODEL 2, Error correction: H, Cell size font: 05, Manual setting, Normal mode, Version 35
<A>
<V>100<H>100 <2D30>,H,05,0,0
<QV>35
<DN>0011,0123456789X
<Q>1
<Z>

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
