SATO CL4NX Programming Reference

211
[ESC+EU] Composite symbol
ESC EU ParameterHexadecimal code
<1B>
16
<45>
16
<55>
16
aaabbn...n
Initial value Nil
When the power is OFF The set parameter is not maintained.
Valid range within items The set parameter becomes invalid.
Valid range and term of
command
Valid range between items The set parameter becomes invalid.
[Function]
Specifying the composite symbol of EAN/UCC.
[Format 1]
<EU>aabbccn...n
• Parameter
a [Type of composite symbol]
01 : GS1 DataBar Composite (CC-A/CC-B)
02 : GS1 DataBar Truncated Composite (CC-A/CC-B)
03 : GS1 DataBar Stacked Composite (CC-A/CC-B)
04 : GS1 DataBar Stacked Omni-Directional (CC-A/CC-B)
05 : GS1 DataBar Limited Composite (CC-A/CC-B)
06 : GS1 DataBar Expanded Composite (CC-A/CC-B)
/GS1 DataBar Expanded Stacked (CC-A/CC-B)
07 : UPC-A Composite (CC-A/CC-B)
08 : UPC-E Composite (CC-A/CC-B)
09 : EAN13 Composite (CC-A/CC-B)
10 : EAN8 Composite (CC-A/CC-B)
b [Narrow bar] = 01 to 12 dots
c [Segment width] = 02 to 22 (Even number only)
* Only GS1 DataBar Expanded Composite (CC-A/CC-B) are supported.
n [Print data] = Data
Maximum number of digit for 1D barcode data
GS1 DataBar Composite (CC-A/CC-B) 13 digits
GS1 DataBar Truncated Composite (CC-A/CC-B) 13 digits
GS1 DataBar Stacked Composite (CC-A/CC-B) 13 digits
GS1 DataBar Stacked Omni-Directional (CC-A/CC-B) 13 digits
GS1 DataBar Limited Composite (CC-A/CC-B) 13 digits
GS1 DataBar Expanded Composite (CC-A/CC-B)
/GS1 DataBar Expanded Stacked (CC-A/CC-B)
74 digits
UPC-A Composite (CC-A/CC-B) 11 digits
UPC-E Composite (CC-A/CC-B)
Specify with "XX00000XXX" (X: variable) format.
Fixed 10 digits
EAN13 Composite (CC-A/CC-B) 12 digits
EAN8 Composite (CC-A/CC-B) 7 digits
◦ Check digit is automatically calculated and added.
