SATO CL4NX Programming Reference

701
Specification of SNMP
SNMP is a protocol to monitor and control network devices connected to network.
This product supports communication with SNMPv1, SNMPv2c, SNMPv3, and MIB supports
following MIB-II. With this MIP, it is possible to acquire information, to send notification on
administrative information, and to change settings.
• system(1)
• interface(2)
• at(3)
• ip(4)
• icmp(5)
• tcp(6)
• udp(7)
• snmp(10)
• host(25)
• printerMIB(43)
HostResourceMIB/printerMIB is used for showing the status of this product. Please refer to the next
page for the details.
PrinterMIB / HostResourceMIB (T.P.D) to show the status of printer
Parent topic LAN/Wireless LAN

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
