SATO CL4NX Programming Reference

71
Font command
[ESC+X20] X20 font (Basic size 5 x 9 dots)
[ESC+X21] X21 font (Basic size 17 x 17 dots)
[ESC+X22] X22 font (Basic size 24 x 24 dots)
[ESC+X23] X23 font (Basic size 48 x 48 dots)
[ESC+X24] X24 font (Basic size 48 x 48 dots)
[ESC+XU] XU font (Basic size 5 x 9 dots)
[ESC+XS] XS font (Basic size 17 x 17 dots)
[ESC+XM] XM font (Basic size 24 x 24 dots)
[ESC+XB] XB font (Basic size 48 x 48 dots)
[ESC+XL] XL font (Basic size 48 x 48 dots)
[ESC+OA] OCR-A font
[ESC+OB] OCR-B font
[ESC+U] U Font (Basic size 5 x 9 dots)
[ESC+S] S Font (Basic size 8 x 15 dots)
[ESC+M] M Font (Basic size 13 x 20 dots)
[ESC+WB] WB Font (Basic size 18 x 30 dots)
[ESC+WL] WL font (Basic size 28 x 52 dots)
[ESC+$] Outline Font Design
[ESC+$=] Outline Font Print
[ESC+RD] CG Font
[ESC+RG] Multiple language
[ESC+RH] Scalable font
[ESC+K1] 16 x 16 dots Kanji in horizontal line
[ESC+K2] 24 x 24 dots Kanji in horizontal line
[ESC+K3] 22 x 22 dots Kanji in horizontal line
[ESC+K4] 32 x 32 dots Kanji in horizontal line
[ESC+K5] 40 x 40 dots Kanji in horizontal line
[ESC+K8] 16 x 16 dots Kanji in horizontal line with 1-byte character
[ESC+K9] 24 x 24 dots Kanji in horizontal line with 1-byte character
[ESC+KA] 22 x 22 dots Kanji in horizontal line with 1-byte character
[ESC+KB] 32 x 32 dots Kanji in horizontal line with 1-byte character
[ESC+KD] 40 x 40 dots Kanji in horizontal line with 1-byte character
[ESC+k1] 16 x 16 dots Kanji in vertical line
[ESC+k2] 24 x 24 dots Kanji in vertical line
[ESC+k3] 22 x 22 dots Kanji in vertical line
[ESC+k4] 32 x 32 dots Kanji in vertical line
[ESC+k5] 40 x 40 dots Kanji in vertical line
[ESC+k8] 16 x 16 dots Kanji in vertical line with 1-byte character
[ESC+k9] 24 x 24 dots Kanji in vertical line with 1-byte character
[ESC+kA] 22 x 22 dots Kanji in vertical line with 1-byte character
[ESC+kB] 32 x 32 dots Kanji in vertical line with 1-byte character
[ESC+kD] 40 x 40 dots Kanji in vertical line with 1-byte character
[ESC+T1] 16 x 16 dots external font registration
[ESC+T2] 24 x 24 dots external font registration
[ESC+K1(K2)] Recall horizontal writing external character
[ESC+k1(k2)] Recall vertical writing external character
Parent topic Part 1 SBPL Commands
[ESC+X20] X20 font (Basic size 5 x 9 dots)
ESC X20 ParameterHexadecimal code
<1B>
16
<58>
16
<32>
16
<30>
16
,n...n
Initial value Nil
When the power is OFF The set parameter is not maintained.
Valid range within items The set parameter becomes invalid.
Valid range and term of
command
Valid range between items The set parameter becomes invalid.
[Function]
Font with the basic size of: width 5 dots, height 9 dots is specified.
[Format]
<X20>,n...n
• Parameter
n [Print data] = Data
[Coding example]
<A>
<V>100<H>200<P>2<L>0304<X20>,ABCDE
<Q>2
<Z>
[Notes]
• The X20 font only allows the setting of a fixed pitch.
[Valid Commands]
Print position <V> <H>
Modification <P> <L> <%> <F> <&> </> <0> <WD>
Barcode <D><d> <BL><d>
Calendar
<WA>
*1
*1 This command requires optional calendar IC.

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
