40
[ESC+%] Rotation
ESC % ParameterHexadecimal code
<1B>
16
<25>
16
a
Initial value a=0
When the power is OFF The set parameter is not maintained.
Valid range within items The set parameter is valid until the next valid setting.
Valid range and term of
command
Valid range between items The set parameter becomes initial value at the next item
<A>.
[Function]
Specifying the counter-clockwise rotation of font and barcode.
[Format]
<%>a
• Parameter
a [Rotative direction]
0: Parallel 1 (0 degree)
1: Serial 1 (90-degree)
2: Parallel 2 (180-degree)
3: Serial 2 (270-degree)
[Coding Example]
Font rotation: Parallel 2 (180-degree), Barcode rotation: Serial 1 (90-degree)
<A>
<%>2
<V>100<H>400<P>3<L>0403<XM>ABCD
<%>1
<V>400<H>200<BD>103160*123*
<Q>2
<Z>
[Supplementary Explanation]
• Position specification of Vertical Print Position <V> and Horizontal Print Position <H> are the
absolute value from its base reference point.
• When the value of parameter "a" is between 4 and 9, it will be processed as a command error
and ignored. When the value other than numeric is specified, this will be ignored and printing
will be performed at 0 degree.
• Print of barcode using Serial 1 or Serial 2 may cause blur. Drop the print speed for rotation print
of Serial 1 and Serial 2 for better performance.
To Next Page
