SATO CL4NX Programming Reference

651
READY/BUSY
This communication protocol controls the reception of print data by the control of hard signal only
without having software methods.
When the print data (STX <A> ~ <Z> ETX) has been sent from the host in the conditions below,
received data may not be accurate:
1) When the printer is in offline state.
2) When an error has occurred in the printer.
Connection diagram
I/O signal
Timing chart of multiple receive
Parent topic RS-232C
Connection diagram
1) DB-9P
Printer
Host
CD
1
1
CD
RD
2
3
SD
SD
3
2
RD
ER
4
6
DR
SG
5
5
SG
DR
6
4
ER
RS
7
8
CS
CS
8
7
RS
Parent topic READY/BUSY
I/O signal
Pin No. Signal
name
I/O Description
2 RD Input Data transferred from the host to the printer
3 SD Output Data transferred from the printer to the host
4 ER Output Data device ready
5 SG - Signal ground
6 DR Input Data set ready
7 RS Output Transmission request
8 CS Input Transmission available
Parent topic READY/BUSY

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
