[DC2+PJ] EPC code read (UHF M6e) (CL4NX Only)
Command DC2 PJ Parameter
Hexadecimal code <12>
16
<50>
16
<4A>
16
,aa,bb
Initial value None
When turning off the power -
Valid range -
Printer operation in progress The command cannot be received
during the printer operation. ([NAK]
return)
When acquiring label sensor
information
Commands are not accepted while
acquiring sensor information. ([NAK]
reply)
Valid range and term of command
Error Commands can be received even if
an error is occurring.
[Function]
Read the information of Gen2 (Class1Generation2) corresponding tags and IC chip manufacturer
extended specifications tag (UHF).
[Format]
[DC2]PJ,aa(,aa)(,aa)(,aa),bb
[Parameters]
Symbol Parameter name Valid range Acquisition method
a Identifier U1: EPC area
U2: TID area
U3: USER area
U4: PC/AFI area
Two characters fixed
acquisition
* More than 1 can be
specified
b Options identifier NO: No option identifier
RS: RSSI/ RSSI(Received Signal Strength
Indicator)
MT: Module temperature
Two characters fixed
acquisition
Only for UHF
[Return data format (normal)]
[STX]a…a,b…b(,c…c)[ETX]
[Return data]
Symbol Parameter name Valid range
a Total number of data byte
* This is the total number of bytes after
parameter b. The delimiting comma between
parameters a and b, and the ETX are not
included.
Data size from the first memory data item until
before [ETX]
Maximum 3 digits
b Memory data During a tag error, "EPC_Tag_Err" is set.
