SATO CL4NX Programming Reference

652
Timing chart of multiple receive
1) Normal process
2) Error process
Power On
Printer
ER
RD
RS
Initializin
g
STX..ETX
(
1
)
Receive/Anal
y
sis/Edit
(
1
)
Printin
g
(
1
)
Online
Receive buffer near full state Receive buffer near full release
STX........ETX
(
3
)
Offline
Receive/Anal
y
sis/Edit
(
3
)
Printin
g
(
3
)
Note: It is possible to send data during printing in the multiple receive mode.
Printer Status
Press the LINE
button
Press the LINE
button
Receive/Anal
y
sis/Edit
(
2
)
STX..ETX
(
2
)
STX........ETX
(
4
)
Receive/Anal
y
sis/Edit
(
4
)
Printin
g
(
2
)
Printer
ER
RD
RS
STX..........ETX
(
1
)
Receive/Anal
y
sis/Edit
(
1
)
Printin
g
(
1
)
Online
Press the LINE
button
Pa
p
er end error Offline
Offline
Printin
g
(
1
)
* When the paper end error occurs, open the head, set label, close the head and feed.
Note: (1) The paper end error will be released when the head is closed.
Printer Status
Head open Head close
Press the LINE button
Receive/Anal
y
sis/Edit
(
2
)
STX............ETX
(
2
)
*
Printin
g
(
2
)
Offline
Online

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
