Notes
Common with LAN /Wireless LAN interface
Wireless LAN interface
LAN Interface
Parent topic LAN/Wireless LAN
Common with LAN /Wireless LAN interface
1. 150ms to 200ms interval is required to close port then open port, if you want to open and close
print data port (Port 1), Status port (Port 2) and send/received port (Port 3). Short interval
setting may cause double connection. Request for double connection occurs when [CONNECT]
request is made to Port (Port1, Port2 or Port3) in addition to the request [CONNECT (Socket
OPEN)] which has already been made to Port (Port1, Port2 or Port3). When printer receives
request for double connection, it sends response of Disconnection (Socket CLOSE) to the
request.
Parent topic Notes
Wireless LAN interface
1. Communication distance and transmission rate between host and printer (Wireless LAN board)
varies by operating environment due to operating conditions of Wireless LAN.
2. It is recommended to use it in Infrastructure mode on the condition that display of field intensity
of Wireless LAN is level3 or above (following chart)
3. It is likely that communication data is lost if environment of WirelssLAN is not appropriate
because Wireless LAN is portable or due to ambient conditions.
4. Please set frequency of channel for each group to every [5 channel] or more than 5 channels if
you want to place few Wireless LAN network groups next to each other.
Ex) When channel of group1 is [1], channel of group 2 shall be set to [6] channel or after.
Parent topic Notes
LAN Interface
1. Communication may not be established if you plug in/out LAN cable while PC is connected. Do
not plug in/out LAN cable while starting up printer. When LAN cable is removed/inserted and it
caused communication loss, please turn on the power of printer again.
Parent topic Notes
