Physical Specifications
Data interface: Standard SCSI to Macintosh or PC
Dimensions (WxHxD): 840 x 340 x 410mm (33 x 13
1
/2 x16”)
Weight: 39 kg. (86lbs)
Power consumption: 250 W
Power supply: 50 - 60 Hz,
100/120/220/240VAC
Fuse: T-4A
General Cautions
1 • GENERAL INFORMATION
Edition 1 • January 1996 Service Manual • ScanMate 4000/5000
1•5
Caution! ☛ Turn off power Before connecting or disconnecting SCSI cables.
Before carrying out service or adjustment operations.
☛ When starting up, always turn on the SCSI units first (including the scan-
ner) and the computer last.
☛ When handling, always lift the ScanMate 4000 and 5000 by their bases.
☛ Do not obstruct the ventilation intakes on the rear of the scanners.
☛ The drums must be handled with utmost care to avoid scratches. Use only
non-abrasive repro wipes and graphic arts drum cleaner to clean the
drums.
☛ The ScanMate 4000 and 5000 are class 1 electrical equipment and must
be connected to a single phase mains outlet with a protective ground
(earth). Never connect the scanners to the mains without a protective
ground.
☛ Always test White calibration (section 5•5), Focus calibration section 5•4),
Register error (section 5•12) and Stripes in shadow (section 5•13) after
every part replacement and service operation.
