Schaerer Ambiente 2 Service Manual

Chapter 4 Fault diagnosis
114 SMSO-2-02.04- 15.07.03
Instant heater does not heat up
System / component Possible cause Remedy
Instant heater  Heating defective or heavily calcified  replace (see “Maintenance, instant
heater tea”)
Electrical faults
Power PCB
 Faulty power PCB, power relay, cabling
or plug
 carry out checks (see control system
diagram, power PCB” and “heating for
instant heater tea”)
Safety thermostat(s)  Safety thermostat(s) triggered as a re-
sult of over-temperature in the instant
heater
 Find out the cause of the over-heating;
reset the safety thermostat, or if there
are visible traces of the effects of heat,
replace.
Unit control system  defective  replace (see “Maintenance, unit control
system”)
 Load machine data (counter and set-
tings) to new unit control system
Programming
 Tea instant heater heating is locked  Correct the programming (see pro-
gramming instructions)
Over-pressure in instant heater
System / component Possible cause Remedy
Electrical faults
Power PCB / power relay
 Power PCB, power relay defective (con-
tacts bonded, and thus no longer switch
off)
 check and replace the power PCB or
power relay (see control system dia-
gram, heating for instant heater tea”)
Temperature sensor  Temperature sensor defective or calci-
fied
 clean or replace and carry out checks
(see “control system diagram, tempera-
ture sensor tea”)
Unit control system  defective  replace (see “Maintenance, unit control
system”)
 Load machine data (counter and set-
tings) to new unit control system
Programming
Instant heater
 Temperature incorrectly programmed  Correct the programming (see pro-
gramming instructions and “Technical
Data, standard settings”)
