Chapter 5 Dismantling components
SMSO-2-02.05- 15.07.03 131
5.4.2 Bean container
For safety information see the section entitled
“Safety Regulations”
Dismantling
1. Place the cups to one side
2. Remove the cup plate frame; if necessary wipe the cup
plate dry.
3. Insert the sliding hatch fully into the bean container,
check its seating
4. Unscrew the safety screw on the tubulure
5. Pull the bean container out of the tubulure
Installation
Work steps 5… 1 have to be carried out in reverse order
to the dismantling procedure.
Replace the sliding hatch to the cleaning material.
