Chapter 5 Dismantling components
SMSO-2-02.05- 15.07.03 163
5.5 Service
5.5.1 Replace heating foil
For safety information see the section entitled
“Safety Regulations, PCBs”
Preparation
Dismantle the cup plate
Maintenance
1. Loosen the cable from the plug; loosen the cable
shackle and pull out the cable
2. Carefully loosen the faulty heating foil with a rounded
knife tip and pull away
3. Use a cleaning agent (cleaning benzine or acetone) to
clean off any residues of adhesive on the cup plate
4. Pull the protective film off the new heating foil; stick the
heating foil cleanly in place
5. Pull the cable through the protecting tube, screw the
cable shackle firmly, and insert the cable into the plug.
