Chapter 5 Dismantling components
136 SMSO-2-02.05- 15.07.03
Adjusting the grinding degree
The grinding degree can be set only when the
grinder is operating.
The grinding degree is adjusted by turning the worm gear
The table below gives the adjustment steps
Grinding degree set-
ting
Number of clicks of the grinding
degree disk (take note of the
direction of rotation).
+/- 10% 5
+/-20% 10
+/- 30% 15
+/- 40% 20
+/- 50% 25
over 50% Readjust the grinding degree disk
Example:
The grinding degree of the left-hand grinder should be
around 20% coarser (see table above).
Turn the worm gear 10 clicks in anticlockwise direction.
Adjusting the “grinder empty” message
See programming manual “General Parameters”
