Connecting the Device 4.5 Relay outputs
INTECONT® Satus Operating Manual BV-H2346GB / 0833 9
© Schenck Process
4.4 Pulse output point for totalizing counter-impulse
55
5
6
+
OUT5+
OUT5-
+24 VDC
-
XNA
Fig. 10: Impulse output connection diagram
4.5 Relay outputs
Fig. 11: Relay outputs connection diagram
