7 Operation
7.1 Mains voltage ON
The counter reading
•
Yet-undisplayed counter pulses
•
Preselected normal display
•
Service values such as duty rate etc.
•
are stored for unlimited time
during a mains failure.
The internal clock will run for a further approx. 5 days.
An automatic display self-test will start once the mains is turned on. The device version
number is displayed for several seconds and then replaced by the normal display.
7.2 Normal display
On the left Rotating point as belt-motion indicator.
The scales is on, feed rate and flow rate are recorded.
Only belt load and belt speed are measured in the shut-down state
(point unmoving).
If an event is pending it is indicated by an event message
(alphanumeric code).
The display then alternately shows the belt-motion indicator and
event message for approx. 5 seconds each.
To the right Selectable display
Preselect display
Counter Z1 Z1 = 5000 kg
Feed rate I = 1000 kg/h
Feed rate Ir = 50.00 % 1)
Belt load Q = 10.000 kg/m
Belt load Qr = 50.0% 2)
Belt speed V = 0.0500 m/s
1) Based on the nominal feed rate
2) Based on the nominal belt load
Display format and dimensions of Z1 and I can be selected separately.
7.2 Normal display Operation
16 BV-H2346GB / 0833 Operating Manual INTECONT® Satus
© Schenck Process
