11.5 Set option
INTECONT Satus has the option of activating the ETHERNET/IP fieldbus coupling via
software. This unit issues an unambiguous ID (the MAC address). An activation code is
generated from this ID that is then keyed into the unit.
If it is necessary to activate the option on units already supplied, the data are transmitted to
Schenck Process and the generated activation code is switched back.
The Set Option function is only accessible when the fieldbus protocol is set to NO or
ETHERNET/IP is stopped.
a) Option OK if activated
or
b) Option not OK! if not activated.
In case a), the function ends automatically after 3 seconds and it skips to normal operation.
In case b), the MAC-ID is shown
For example, 00:15:84:01:03:ee
Note this value and then show the desired ETHERNET/IP option
Also note this value and report to Schenck Process
Code 11 111
Key in the activation code from Schenck Process.
Message and cancel
OPTION OK! Call up the PROGRAMMING function, Set Option.or fault
11.5 Set option Parametrization
34 BV-H2346GB / 0833 Operating Manual INTECONT® Satus
