Special Notes:
1. SWITCH ON if the belt is not running
2. ABORTED (no significance)
* This display can be used to monitor the zero point of the scales without a
calibration weight.
Display format: xxxxxxx,yy kg
Evaluating the results:
Error<1% : KOR=0.99 - 1.01
The scales condition is fine, no further measures are necessary.
Error < 5% : KOR = 0.95 - 1.05
Enter the KOR value into parameter D 02.
Of course, this is only effective if the result of a material control has been
allowed for in the parameter.
Error>5% : KOR<0.95 or KOR > 1.05
Deviations of several percent indicate incorrectly entered technical data
(e.g. unknown exact belt incline, levers, etc.) or mechanical errors
(alignment, tension).
The ‘Range Corrector’ parameter D 02 is not accounted during control.
Fot this reason the control program will display the same error quotient KOR after the
correction.
9.5 Setting the time
Unlike the other programs, the date and time can be altered with the scales either on or off.
It can be found at SERVICE VALUE.
Function distributor, adjustment functions, password
(see section ‘Adjustment Functions’)
Scroll ‘Set Time’
into the lower part of the display.
Call up the menu.
May be aborted at any time.
Enter the Year, e.g. 06
Month, Day, Hour, Minute and Second.
Confirm each entry.
After the seconds have been entered and confirmed, the new time will
be accepted.
Subsequently the complete date will be displayed for a few seconds.
The internal clock will run for a further approx. 5 days in case of a mains failure.
Setup Program 9.5 Setting the time
INTECONT® Satus Operating Manual BV-H2346GB / 0833 27
© Schenck Process
