14 PROFIBUS DP
The following chapter describes the coupling of the Profibus slave INTECONT® Satus to a
Modbus master component group.
The Profibus connection functionality, the data exchange between the Profibus master and
the INTECONT® Satus and notes on troubleshooting and diagnosis are all described. The
Profibus hardware connection is described in the chapter ‘Profibus Module VPB8020’..
14.1 Guidelines for commissioning
1. Preparing the hardware as described in the chapter ‘Profibus Module VPB8020’.
2. Setting the INTECONT® Satus - ‘Address’ parameter
3. Creating master parameter sets using the GSD file
4. Start communication by the master
14.2 Functionality of the Profibus connection
n
Certified connection after specification EN 50170
n
A cyclical data exchange is performed with the master (DP-V0)
n
Automatic baud rate detection
n
Monitoring the bus interface
n
The VPB8020 is easily parametrized using the basic model’s operating station or the Ea-
syServe diagnostic tool.
n
Profibus control command SYNC support for synchronized data transmission from mas
-
ter to several slaves.
n
Profibus control command FREEZE support for synchronized data transmission from se
-
veral slaves to the master.
n
No operator-specific diagnostic functions
n
Failsafe: Clear state does not support
n
any alteration of the station address via bus.
14.3 Structure of user data
Details on and examples of the structure of user data can be found in the chapter
‘Fieldbusses User Data Structure’.
14.3 Structure of user data PROFIBUS DP
70 BV-H2346GB / 0833 Operating Manual INTECONT® Satus
© Schenck Process
