5 Technical data and replacement parts
5.1 Technical Data
View LCD back lighting. 1 cell 20 characters. Characters
12,4mm high
Keyboard 6 keys
Supply voltage 100-240 VAC +10% -15%, 50-60Hz, max. 10 VA
Housing Stainless steel 1.4301, deep drawn, IP 65
Temperature range Service temperature: -30...+60 °C
Measuring ciruit Suppy voltage: 5V alternating current
supply
Range –20mV…+20mV;
Load cell impedance: Rmin 80Ω
Cable length: max. 500m
Units kg, t, lb; kg/h, t/h, lb/h;
Taring to be started via digital input or keyboard
Belt monitoring zero-drop-out; Belt load >max/<min
Binary inputs
3 x Optocoupler, 18-36 VDC, typ. 5 mA
1 x NAMUR, max. 5V, 0,04-3000Hz
assigned signal
Ack. event
Tare
External event
Tacho input
Binary outputs
4 x relay, 230 VAC, 60W max.
Pulse output
Optocoupler, 18-36VDC, max. 50 mA/10Hz
Running
Belt load Q>Max
Alarm
Belt load Q<Min
Totalizing counter pulses
Analog output
0–20mA, 12 Bit, max. Burden 500Ω
Feedrate
Serial connections
Interface 1: RS 232
Interface 2: RS 232
Interface 3: RS 485,2/4-wire
Ethernet
Optional PROFIBUS DPV0, DeviceNet, Ethernet/IP
EasyServe
- not used –
Modbus fieldbus
Modbus/TCP fieldbus/EasyServe
Technical data and replacement parts 5.1 Technical Data
INTECONT® Satus Operating Manual BV-H2346GB / 0833 11
© Schenck Process
