Note:
1. The tare may exceed 100% by using the nominal belt load as reference.
2. A mechanical error may be at fault if the deviation ‘Dev.’ is high (>20%).
Inspect the weighing platform for e.g. stuck particles of material.
9.4 Weight Control CW
This program can be used to control the INTECONT measuring range.
This is done by loading the weighing platform with a known calibration weight and
automatically calculating the average platform load over one belt circuit.
The result is compared to a predetermined reference value and then displayed.
No automatic correction is performed.
Preconditions:
1. Taring
2. Enter the calibration weight into parameter C 08.
The calibration weight should be between 30 - 100% of the nominal platform load Q0.
Q0 = q0 * Leff
q0 = Nominal belt load Parameter D 01
Leff = Effective bridge length Parameter C 05
3. Put the calibration weight on the specified spot.
4. Turn on the belt conveyor.
A corresponding message occurs automatically.
Procedure:
Function distributor, adjustment functions, password
(see section ‘Adjustment Functions’)
CW: Scroll ‘Weight Control’ into the lower part of the display
Start
May be aborted at any time
Program running:
Display:
(alternates)
- Remaining running time as % of overall running time.
Continuously averaged NOMINAL/ACTUAL measuring result.
Program ended:
Display:
(alternates)
- Notional transported material quantity over running time *.
- Average KOR from the NOMINAL/ACTUAL values over the total
running time.
Exiting the program.
Either button may be used as the result is not taken over
automatically.
9.4 Weight Control CW Setup Program
26 BV-H2346GB / 0833 Operating Manual INTECONT® Satus
© Schenck Process
