Preconditions:
1. Measure the time required for one belt circuit as accurately as possible and enter this
time for parameter C 02.
2. The belt conveyor must be running
Note:
The belt drive is not controlled by the setup program.
The setup program will be interrupted with a corresponding message if one of the
preconditions is not met.
Procedure:
Function distributor, adjustment functions, password
(see section ‘Adjustment Functions’)
Scroll LB: IMP/Belt
into the lower part of the display
Start
May be aborted at any time
Program running:
Display:
(alternates)
- Remaining running time in seconds
- Summed impulses of the speed sensor
Program ended:
Display:
(alternates)
- Mean belt speed over entire run time
- Impulse/belt circuit end result
The result is accepted and stored in parameter D 06.
The result is not taken over.
The procedure is identical for models without speed sensor.
Specific messages:
1. SWITCH ON, if belt is not running
2. ABORTED
9.2 Belt circuit LB Setup Program
24 BV-H2346GB / 0833 Operating Manual INTECONT® Satus
© Schenck Process
