BLOCK F Limit Values
F 05 Q-MIN Value 20.0 % Q
F 06 Q-MIN Event Class W2 (L 02)
F 07 Q-MAX Value 120.0 % Q
F 08 Q-Max Event Class W2 (H 02)
F 09 V-MIN Value 5.0 % V
BLOCK G Filter settings
G 01 I Display 3 s
G 02 I Analog output 3 s
BLOCK H Zero setting
H 09 ZDO active NO
H 10 ZDO limit 1.00 %Q
BLOCK L Fieldbus
L 01 Protocol Type NO
L 02 Timeout Host 5s
L 03 Host Communic. IG (S 09)
L 04 Word Sequence I:std/L:std
L 05 Byte Sequence High - Low
L 06 Configuration FIXED
L 07 Address 1
L 08 Resolution 4096
L 09 Baud rate 9600
L 10 Data Format 8-E-1
L 11 Physics RS 485 2-wire
L 12 Address 16
L 13 FLOAT Format IEEE
L 14 Address 63
L 15 Baud rate 125K
BLOCK O Events
O 01 Power Failure W1 (E 01)
O 02 Memory Error A (S 01)
O 03 Tachometer Input W1 (C 02)
O 04 Namur Err. Tacho A (E 02)
36 BV-H2346GB / 0833 Operating Manual INTECONT® Satus
© Schenck Process
11.5 Overview of Parameters
