Schenck process Intecont Satus User Manual

BLOCK O Events
O 06 LC Input A (C 01)
O 08 LC Input > MAX W1 (H 04)
O 09 LC Input < MIN W1 (L 04)
O 11 Error Ext. Event A (E 06)
O 15Dongle fault S5 W2 (S05)
BLOCK P Digital Inputs
P 03 DI Ackn. Events DI VFE.DI1 H
P 05 DI Tare DI VFE.DI2 H
P 06 DI External Event DI VFE.DI3 H
P 07 DI calibration switch DI VFE.DI7 H
BLOCK Q Digital Outputs
Q 01 DO ALARM DO VFE.DO3 L
Q 03 DO Scale ON DO VFE.DO1 H
Q 06 DO Q-MIN DO VFE.DO4 L
Q 07 DO Q-MAX DO VFE.DO2 L
BLOCK R EasyServe serial
R 01 Station address 1
R 03 Baud rate 19200
R 04 Data Format 8-O-1
BLOCK T Ethernet
T 01 IP Address 1 192
T 02 IP Address 2 168
T 03 IP Address 3 240
T 04 IP Address 4 1
T 05 Net Mask 1 255
T 06 Net Mask 2 255
T 07 Net Mask 3 255
T 08 Net Mask 4 0
T 09 Gateway 1 0
T 10 Gateway 2 0
T 11 Gateway 3 0
T 12 Gateway 4 0
11.5 Overview of Parameters
INTECONT® Satus Operating Manual BV-H2346GB / 0833 37
© Schenck Process
