Schenck process Intecont Satus User Manual

Block R: Serial EasyServe
R 01 Station address
Range: 1...254 Preconfigured value: 1
The station address and scales and EasyServe baud rates must correspond.
The settings (including the Com interface) can be located using EasyServe (menu:
Extras/Options/Communication).
The station address is intended specifically for systems with ‘Servicebus’. If no Servicebus is
available ‘1’ should be selected.
It is connected to a PC via the serial interface S1, see the connection diagram in the
‘Connecting the Device’ chapter.
Alternatively, EasyServe can be connected via the Ethernet; the IP address is set in block T
(Ethernet MBTCP).
R 03 EasyServe baud rate
Range: 9600
19200
38400
Preconfigured value: 19200
Data Transmission Rate.
R 04 Data Format
Range: 8-0-1
8-E-1
8-N-1
Preconfigured value: 8-0-1
Example:
8-0-1 means:
1 Start bit, 8 Data bit, Odd parity, 1 Stop bit
(N = No Parity, E = Even Parity)
56 BV-H2346GB / 0833 Operating Manual INTECONT® Satus
© Schenck Process
