Block Q: Digital Outputs
Q 01 DO Alarm
D03 Level L: No changes possible.
Digital output for displaying a combined alarm.
Q 03 DO Scales ON
D01 Level H: No changes possible.
Digital output signal to display the ON or OFF scales state.
The same output can also be used to turn the drive on or off.
Q06 DOQ-MIN
D04 Level L: No changes possible.
Digital output signal if the belt load falls below the minimum belt load (F05).
The contact output is independent of the event class (F06).
Q07 DOQ-MAX
D02 Level L: No changes possible.
Digital output signal if the belt load falls goes above the maximum belt load (F07).
The contact output is independent of the event class (F08).
INTECONT® Satus Operating Manual BV-H2346GB / 0833 55
© Schenck Process
