Block P: Digital Inputs
P 03 DI Acknowledge Event
DI1 Level H: No changes possible.
Digital input for acknowledging event messages.
The level is static and should not be on permanently (continuous acknowledgement).
P 05 DI Taring
DI2 Level H: No changes possible.
The taring calibration function can also be started via the digital input. The program is
started by a positive contact slope. The result is transferred automatically, it is not necessary
to acknowledge the event. The calibration program can only be stopped in its active phase
and only via keyboard, EasyServe or Fieldbus.
P06 DI External Event
DI3 Level H: No changes possible.
Digital input for external noise signals.
P 07 DI calibration switch
DI7 Level H: No change possible
Digital input that shows dongle write-protection.(”1” write-protection active; “0” writing
possible).
The parameters cannot be changed any more if write-protection is active.
54 BV-H2346GB / 0833 Operating Manual INTECONT® Satus
