Description of highest priority event
ID (hex) ID (dec) Description
0610 1552 Highest-priority event (LO)
Bit0-3 Event Number
Range0–8, (corresponds to display1–9)
Bit4-7 Event Group
Range 1 – 12, (S = 1, E = 3, B=5, C=9, H=10, L=11)
Highest-priority event (HI)
Bit8-11 Event Class
Range1–4, (A=1, W1=2, W2=3, (IG=4))
Bit 12 - 15 Acknowledge Event
Range0–1,(Acknowledged = 1, Not Acknowledged =
0)
Parameter block which contains the event class (Byte)
Number in the parameter block (Byte)
Description of the measured values
ID (HEX) ID (DEC) Value
0750 1872 Actual feed rate [kg/h]
0752 1874 Totalizing counter 1 [kg]
0754 1876
0756 1878
0758 1880 Belt load [kg/m]
075A 1882
075C 1884 Belt speed [m/s]
Measured values in integer format (Modbus)
ID (HEX) ID (DEC) Value
30 48 Actual value [kg/h] - 0 to MAXPARTS=0to300%
P
31 49 Totalizing counter 1 [kg]-0toMAXPARTS=0toP
* 8 hours
32 50
33 51
34 52 Belt load [kg/m]-0toMAXPARTS=0to200% Q
Fieldbusses 13.3 Fieldbus data
INTECONT® Satus Operating Manual BV-H2346GB / 0833 65
© Schenck Process
