Status
Status Indication
Off Not power or not initialized
Green Initialized
Flashing Green Initialized, diagnostic event(s) present
Red Exception error
Pin assignment
Pin Signal (XP1 9-pin
Sub-D-female)
Signal (XP3, 5-pin Phoenix MSTB 3.5
max. 1.5mm²)
1 - B-Line, Positive RS485 RxD/TxD *
2 - A-Line, Negative RS485 RxD/TxD **
3 B-Line, Positive RS485
RxD/TxD *
GND BUS
4 RTS, Request To Send +5V BUS
5 GND BUS Shielding
6 +5V BUS -
7- -
8 A-Line, Negative RS485
RxD/TxD **
-
9- -
Housing Bus Cable Shield -
* This cable has the conductor color red.
** This cable has the conductor color green.
Characteristics
Disconnection Optocoupler
Power supply 5V DC internal
Power supply Max 310mA
Plug connector 5-Pin Phoenix MSTB 3.5 max. 1.5mm²
9-pin Sub-D-femal
PROFIBUS DP 14.6 Profibus module (VPB8020)
INTECONT® Satus Operating Manual BV-H2346GB / 0833 73
