red Critical link failure
Flashing Red (1 Hz) One of more connection timed-out
Alternating Red/Green Self test
Moduel Status LED
Status Indication
OFF No power
Green Operating in normal condition
Flashing Green (1Hz) Missing or incomplete configutation, device needs
commissioning
Red Unreccoverable Fault(s)
Flashing Red (1 Hz) Recoverable Fault(s)
Alternating Red/Greed Self test
Plug assignment X20/XC3
Pin Signal X20
3 Screening
4 CAN_H
2 CAN_L
1V-
5V+
Characteristics
Disconnection Optocoupler
Power supply 5V DC internal
Power supply Max 250mA
Plug connector Phoenix MSTB 5 max. 2.5mm²
Phoenix MSTB 5 max. 1.5mm²
DeviceNet 15.6 DeviceNet module (VCB8020)
INTECONT® Satus Operating Manual BV-H2346GB / 0833 77
