Safety and Functional Tester GLP2-i/e
During the test, test object and test leads must not be touched!
The safety measures required by law must be adhered to!
Schleich GmbH * D-58675 Hemer * 0049 / (0)2372 / 9498-0 * 0049 / (0)2372 / 9498-99 *
http://www.schleich.com * info@schleich.com 71
EN60204 test
At the EN60204 test, the two test methods PE test and insulation resistance test are switched alternately
between the PE and the test probe.
In a connection of the test object, it is possible to test the PE resistance within the machine and the
insulation resistance to the enclosure of the machine.
A
U V
A
ISO PE
V
