Safety and Functional Tester GLP2-i/e
During the test, test object and test leads must not be touched!
The safety measures required by law must be adhered to!
Schleich GmbH * D-58675 Hemer * 0049 / (0)2372 / 9498-0 * 0049 / (0)2372 / 9498-99 *
http://www.schleich.com * info@schleich.com 79
Repeat if no go
on: In case of a “no go” test result, the test step will be repeated. The number of
repetitions is entered in the menu >General data<. This applies to all set values
of every test method.
off: After a “no go” test result, the test is not repeated.
Disable step
on: This test step is not part of the test process. All other test steps of the test method
remain active.
off: The test step will be executed.
Cancel if no go
on: In case of a “no go” test, the test process is interrupted.
off: If there is a fault, it will be continued with the next test step.
Voltage drop (general setting for all PE tests)
off: The test result is indicated in Ohms.
on: The test result is indicated in Volts. This selection is only possible, if you have a test
current of 10A and is a general setting for all PE set values.
Please note:
Under menu point “Offset PE-test” in the menu General Data it is possible to enter a resistance. This is
necessary, if contacting units or test probes have a contact resistance.
At the test, this resistance is deducted from the measured value, so that the contact resistance is not
contained in the measured value. For indicating that this correction has been entered, the set value is
indicated in the test table with k (k = korrigiert = corrected).
No. 100W Lamp St.vl At.vl Res
1 PE (1)
0,20k
2 PE (1)
0,20k
