SciCan STATCLAVE G4 - Page 104

104
ITEM
PART #
PART NAME
INVENTORY DESCRIPTION
7
N/A
Steam generator switch –
safety (part of SG kit)
Steam Generator Switch – Level (Part
of SG Kit)
8
01-110505S
EMI filter
EMI FILTER 20A/250V
9
01-115434S
External fill port
Bulkhead Connector, 1/4",
STATCLAVE
10
01-115431S
Condenser water
compartment drain
Coupling barb, 3/8” Valved
11
01-115433S
Clean water overflow drain
outlet
Bulkhead Connector, 3/8",
STATCLAVE
12
01-115409S
24V DC power (for auxiliary fill
pump)
Cable, DC Power Jack, STATCLAVE
13
01-115411S
RS232 port (for external
printer)
Cable, RS232 Kit, STATCLAVE
14
01-115455S
Chamber thermocouple
Thermocouple Chamber, STATCLAVE
15
See Left side
Steam generator
Steam Generator
16
01-115466S
Solenoid valve VFB – fill
(Boiler) steam generator
Valve Fill Boiler Kit, STATCLAVE
17
01-115454S
Pressure relief valve
Pressure Relief Valve, STATCLAVE
18
01-115451S
Venturi water reservoir
thermistor
Water Temperature Sensor,
STATCLAVE
19
01-115448S
Venturi water reservoir float
switches (high and low)
Float Sensor, Reservoir, STATCLAVE
Not
shown
01-115464S
Condenser and back panel
Condenser
Not
shown
01-115391S
Exhaust drain for condenser
Fitting, Thread 1/4, Tube 3/8"
