SciCan STATCLAVE G4 - Removing and Reinstalling the Left Panel; Removing and Reinstalling the Right Panel

95
6.1 Removing and reinstalling the left panel
1. Remove the 2 screws.
2. Slide the panel to the rear to disengage the tabs at the top and bottom of the panel.
Figure 6.1-1
6.2 Removing and reinstalling the right panel
1. Remove the 2 screws.
2. Slide the panel to the rear to disengage the tabs at the top and bottom of the panel.
Figure 6.2-1
Remove X 2
Remove X 2
