3.2.EXAMPLE OF PROGRAMMER USE
The example below shows how it is possible to set the timer for the parking time on the
landing (or of occupied). (Please refer also to paragraph ‘Timers Programming’)
1. Set Parameter Code 4.02 on displays DG0,DG1,DG2:
1.1. Select DG0, by pressing pushbutton until DG0 flashes:
DG0 DG1 DG2 DG3 DG4 DG5 DG6
DG0 flashes
1.2. Set 4 on DG0 using pushbuttons , :
DG0 DG1 DG2 DG3 DG4 DG5 DG6
4
DG0 flashes
1.3. Select DG1 and DG2, by pressing the pushbutton once
(DG1 and DG2 flash):
DG0 DG1 DG2 DG3 DG4 DG5 DG6
4
DG1and DG2 flash
1.4. Set 2 on DG1,DG2 by pushbutton:
DG0 DG1 DG2 DG3 DG4 DG5 DG6
4 0 2
DG1 and DG2 flash
2. Set the timer time on displays DG3..DG6:
2.1. Select displays DG3, DG4, DG5, DG6 by pressing the pushbutton once
DG0 DG1 DG2 DG3 DG4 DG5 DG6
4 0 2
DG3..DG6 flash
2.2. Set the time (i.e. 8 seconds = 80 tenths of a second) by pushbutton
DG0 DG1 DG2 DG3 DG4 DG5 DG6
4 0 2 0 0 8 0
DG3..DG6 flash
NOTA
The value set is operational by pressing once, but it is not stored.
For the storing please refer to paragraph 3.4_Parameters Storing..
