ROGRAMMING OF TIMERS:
DG0 DG1 DG2 DG3 DG4 DG5 DG6
4
TIME
Expressed in tenths of a second
(i.e. 0080 = 8 seconds)
TIMER
00= Max duration of the inter-floor run
01= Max duration run in low speed (if 4.01=0000 Æ the timer is not enabled)
02= Floor parking duration (occupied)
03= Floor parking reduced duration after photocell activation
04= Max duration of the stage side A lift doors opening/closing
(See error codes from 76 to 77)
05= Max duration of the stage side B lift doors opening/closing
(See error codes from 78 to 79)
06= doors opening delay after stop or door re-opening delay with operator 09
07= Max time at start (after the drop out of closing / opening contactors)
08= despatch delay to parking floor
(if 4.08=0000 Æ the timer is not enabled)
09= despatch delay to lower outmost floor (for hydraulic lifts)
(if 4.09=0000 Æ the timer is not enabled)
10= combinable with output functions to be programmed
11= combinable with output functions to be programmed
12= Stop delay to adjust the relevelling space
(see paragraph 2.6.3_‘Relevelling space adjustment’)
13= Max time of the call holding with still car
14= contactors excitation delay at start (this is used to avoid false excitations of operating
contactors due to safety contacts bouncing)
15= doors opening delay due to the activation of the safety circuit (used with door opening
in advance)
