3.7.PROGRAMMING THE OPERATOR
DG0 DG1 DG2 DG3 DG4 DG5 DG6
1 0 5
OPERATOR B
See Operator A
OPERATOR A:
Floor Doors Car Doors Limit switches Notes
00
No Available No Available No Available
01
Manual Manual Nothing
02
Manual safety photocell Nothing
03
Manual Automatic Closing and Opening (1)
04
Manual Automatic Opening (1)
05
Manual Automatic Nothing (2)
09
Automatic Automatic Closing and Opening (1), (4)
10
Automatic Automatic Closing and Opening (1)
11
Automatic Automatic Opening (1)
12
Automatic Automatic Nothing (2)
13
Automatic Automatic Nothing (2), (3)
(1) = Set the timer 4.04 (for Operator A) end/or the timer 4.05 (for operator B) twice the
door closing time;
(Limit switches are controlled: see error codes from 76 to 79)
(2) Set the timer 4.04 (for Operator A) end/or the timer 4.05 (for operator B) equal to the
door closing time;
(3) = The door opening/closing signal is turned off when the set with the timer 4.04
end/or 4.05 is over;
(4) = Set the timer 4.06 (for both operators A and B) to delay the door ri-opening after
the photocell activation (with 4.06.0000 = immediate ri-opening)
Operators with Motor power supplied during the run with closing limit switch:
In case of operators that need to be power supplied during le lift run, it is necessary to use
the input programmable functions 30 and 31 (see par. 3.14)
