4.2.DISPLAY AND CANCELLATION OF FAILURES / MALFUNCTIONS
A).DISPLAY OF THE LAST FAILURE:
Set ‘Parameter Code’ 001 on displays DG0, DG1, DG2:
DG0 DG1 DG2 DG3 DG4 DG5 DG6
0
0 1
FAILURE CODE
NUMBER OF TIMES THE BOARD DETECTED THE FAILURE
(MAX 9)
If the parameter value (DG3..DG6) is 0000, this means that no failure or malfunction has
occurred.
B).DISPLAY OF THE LAST 16 FAILURES:
Set ‘Parameter Code’ 0.02 on displays DG0, DG1, DG2 and press :
DG0 DG1 DG2 DG3 DG4 DG5 DG6
0
0 2
DG3.. DG6 FLASH
FAILURE CODE
NUMBER OF TIMES THE BOARD HAS DETECTED THE
FAILURE (MAX 9)
By pressing pushbutton it is possible to display subsequent failures.
By pressing pushbutton it is possible to display previous failures.
If the parameter value (DG3..DG6) is 0000, this means that no failure/malfunction has
occurred or the end of the failure codes list has been reached.
C).FAILURES CANCELLATION:
1. Set ‘Parameter Code’ 0.03 on displays DG0, DG1, DG2 and press :
DG0 DG1 DG2 DG3 DG4 DG5 DG6
0
0 3 0 0 0 0
DG3..DG6 FLASH
2. Press . The parameter value (DG3..DG6) shows 0001 to indicate that failures have
been deleted:
DG0 DG1 DG2 DG3 DG4 DG5 DG6
0
0 3 0 0 0 1
FAILURES DELETED
