SEA SETRONIK1 - Installation Guide for SETRONIK1 System

SEA SYSTEMS
INSTALLATION AND USE MANUAL
CONTROL PANEL and PREWIRED SYSTEM STK1
For Electric and Hydraulic Lifts
MSTK12-GB
Rev.01
30/12/05
SETRONIK1 Pagina 6 di 54
2.INSTALLATION
Fig.2.1. Pre-wiring Layout Drawing, including reference paragraphs for installation purposes
SHAFT:
- Par. 2.6
CAR ROOF:
- Par. 2.7
MACHINE ROOM:
- Par. 2.5
