SEA SYSTEMS
INSTALLATION AND USE MANUAL
CONTROL PANEL and PREWIRED SYSTEM STK1
For Electric and Hydraulic Lifts
MSTK12-GB
Rev.01
30/12/05
SETRONIK1 Pagina 52 di 54
5.4.CS1 SAFETY CIRCUIT REPLACEMENT
WARNING
The Safety Circuit CS1 has not electronic components with contact function, so it
is not a safety component according to the 95/16 directive.
Should the card be removed for replacement, abide by the instructions reported
below, so as not to jeopardise its safe operation.
1. Before carrying out any operations, make sure that the control panel is de-energised.
2. The CS1 safety circuit is anchored to a DIN guide, driven into the control panel; to
remove the device from the DIN guide, use an appropriate screwdriver to loosen the
upper tab of the device.
WARNING
Do not open the casing covering the CS1 device.
3. Use an appropriate screwdriver to disconnect/reconnect the CS1 device to/from the
control panel.
HIGHLIGHT
In order to avoid making erroneous connections to the CS1 device, we
recommend that you identify each connector with the name of the corresponding
jumper on the CS device before carrying out any connections.
4. Visually inspect the circuit and look out for possible short-circuits between the jumpers.
