SEA SETRONIK1 - LED Signalling Legend for Control Cards

SEA SYSTEMS
INSTALLATION AND USE MANUAL
CONTROL PANEL and PREWIRED SYSTEM STK1
For Electric and Hydraulic Lifts
MSTK12-GB
Rev.01
30/12/05
SETRONIK1 Pagina 44 di 54
4.5.L
ED SIGNALLING LEGEND OF CARDS STK1-B, STK1-E AND AL01
LED CARD PORT
TYPE
STA
TUS
DESCRIPTION
1 STK1-B IN_NP ON Voltage presence on terminal 1 of safety devices
2 STK1-B IN_NP ON Voltage presence on terminal 2 of safety devices
ON Voltage presence on terminal 5 of safety devices
(Maintenance operation)
5 STK1-B IN_NP
OFF Normal operation
8 STK1-B IN_NP ON Voltage presence on terminal 8 of safety devices
10 STK1-B IN_NP ON Voltage presence on terminal 10 of safety devices
+5 STK1-B ON Card power supply voltage presence (5 Volt)
AD STK1-B OUT_N
P
ON Downward run command
ALL STK1-B OUT_N
P
FLAS
HING
Generic alarm:
check the Error code by the programmer STK2-PM
AS STK1-B OUT_N
P
ON Upward command
AV STK1-B OUT_N
P
ON High speed command: K5 relay energised
BA STK1-B IN_NP ON Maintenance door opening push button closed (1
st
operator)
BA1 STK1-E IN_NP ON Maintenance door opening push button closed (2
nd
operator)
BD STK1-B IN_NP ON Maintenance downward push button closed
BKC STK1-B IN_NP ON Maintenance door closing push button closed
BS STK1-B IN_NP ON Maintenance upward push button closed
CE STK1-B IN_NP ON Overload contact closed
CM STK1-B IN_NP ON Door pressure switch, Photocell, Door opening
pushbutton closed (1
st
operator) (N.C. contacts)
CM1 STK1-E IN_NP ON Door pressure switch, Photocell, Door opening
pushbutton closed (2
nd
operator) (N.C. contacts)
D-E STK1-B IN_NP ON Downward contactor (KD) \ contactor excluding
impedance-resistors closed (KE)
DR STK1-B IN_NP ON DR sensor contact closed
DS STK1-B IN_NP ON DS sensor contact closed
ED1..ED6 STK1-B IN_NP ON Floor calls recorded
ED7..ED12 STK1-E IN_NP ON Floor calls recorded
