SEA SYSTEMS
INSTALLATION AND USE MANUAL
CONTROL PANEL and PREWIRED SYSTEM STK1
For Electric and Hydraulic Lifts
MSTK12-GB
Rev.01
30/12/05
SETRONIK1 Pagina 45 di 54
LED CARD PORT
TYPE
STATU
S
DESCRIPTION
EM STK1-B IN_NP ON Lift in emergency (hydraulic)
FD STK1-B OUT_NP ON Down arrow
FFS STK1-B OUT_NP ON Out-of-service
FG STK1-B IN_P ON Full load contact closed
FM STK1-B IN_NP ON Movable platform contact closed
FS STK1-B OUT_NP ON Up arrow
ON 230Vac presence (Clamps L, N)
HCB AL01 IN_NP
OFF 230Vac lack (Clamps L, N)
ON 24Vdc presence (Clamps -, +24)
HPS AL01 OUT_NP
OFF 24Vdc lack (Clamps -, +24)
OFF One or more phases not present (Clamps R, S, T)
Fixed
ON
Right phases (Clamps R, S, T)
HSF AL01 IN_NP
Flashing
ON
Reversed phases (Clamps R, S, T)
I1..I6 STK1-B IN_NP ON Car calls recorded
I7..I12 STK1-E IN_NP ON Car calls recorded
ID STK1-B IN_NP ON ID sensor contact closed
IS STK1-B IN_NP ON IS sensor contact closed
M-AB STK1-B IN_NP ON Run contactor \ high-low speed contactor closed
MP STK1-B IN_P ON Firemen operation key closed
MR STK1-B IN_P ON Reserved operation contact closed
O1 STK1-B OUT_P ON K9 Relay contact closed: generally used for 1st
operator closing command
O2 STK1-B OUT_P ON K8 Relay contact closed: generally used for 1st
operator closing command
O3 STK1-E OUT_P ON K2 Relay contact closed: generally used for 2nd
operator closing command
O4 STK1-E OUT_P ON K1 Relay contact closed: generally used for 2nd
operator closing command
O5 STK1-B OUT_P ON car mobile lighting command: Relay K7 energised
O6 STK1-B OUT_P ON It is matched to the programmable output
J7.1/J7.3 : Relay K6 energised (*)
