INSTALLATION AND USE MANUAL
CONTROL PANEL and PREWIRED SYSTEM STK1
For Electric and Hydraulic Lifts
MSTK12-GB
Rev.01
30/12/05
SETRONIK1 Pagina 39 di 54
3.15.O
UTPUT PROGRAMMING:
DG0 DG1 DG2 DG3 DG4 DG5 DG6
5 00
OUTPUT FUNCTION Timer
00
None
01
Door opening command for operator A (NO) 4.04
Led Term. 02
Door opening command for operator B (NO) 4.05
17
01 32 / J8.2
03
Door closing command for operator A (NO) 4.04
18
02 30 / J8.3
04
Door closing command for operator B (NO) 4.05
19 (*)
03 42 / J9.2
05
Fixed occupied command, car light
20 (*)
04 40 / J9.3
06
Retiring cam command
21
05 J7.1 / J7.2
07
Stop command at stop: for ACVV e 3VF with old interface
22
06 J7.1 / J7.3
08
Soft Starter command
09
Soft Stop command during upward run 4.10
10
Delta contactor command 4.11
12
Soft Stop command during upward and downward run 4.10
(*) = Leds and terminals
are on the expansion
card STK1-E
13
Brake command with 3VF starting 4.11
14
Resistors or impedance exclusion command (SCC) at
start
4.11
15
Resistors exclusion command upon speed change 4.10
16
CS1 enabling (obsolete)
17
Intermediate speed command between short floors with
3VF (obsolete)
18
Intermediate speed command between close floors with
3VF (obsolete)
19
Relevelling command
20
Relay KV1 command for 3VF
21
Relay KV2 command for 3VF
22
Door closing command for both the operators
23
Door opening command for operator A (NC) 4.04
24
Door opening command for operator B (NC) 4.05
25
VMP command with Soft Stop and valve 2CH 4.11
26
Alarm filtering command
NOTE: Functions 0016, 0017, 0018 are obsolete with diagrams based on Eprom 4.00 or
later types.
