3.6.P
ROGRAMMING THE MAIN FLOOR, PARKING FLOOR, PREFERENTIAL FLOOR,
FIREMEN AND FIRE-FIGHTING FLOOR, DUPLO VERTICAL RISE FLOORS
DG0 DG1 DG2 DG3 DG4 DG5 DG6
1 0 2
- PARKING FLOOR (TIMER 4.08)
- PREFERENTIAL OPERATION FLOOR
MAIN FLOOR
DG0 DG1 DG2 DG3 DG4 DG5 DG6
1 0 3
FIREMAN FLOOR #2
(Input Function 9)
FIREMAN FLOOR #1
(Input Function 8 o 22)
DG0 DG1 DG2 DG3 DG4 DG5 DG6
1 0 4
NUMBER OF DUPLO VERTICAL RISE FLOORS
(to be programmed on the panel of the lower lift)
NOTA
Floors numbering starts from number 1 corresponding to the lower external floor
