SEA SYSTEMS
INSTALLATION AND USE MANUAL
CONTROL PANEL and PREWIRED SYSTEM STK1
For Electric and Hydraulic Lifts
MSTK12-GB
Rev.01
30/12/05
SETRONIK1 Pagina 28 di 54
3.4.PARAMETERS STORING.
This parameter execute the command for the permanent storing of the parameters
modified. If this operation is not performed, any modifications made remain valid until the
power supply to the STK1_B boards is cut off.
1. Set Parameter Code 0.12 on displays DG0, DG1, DG2.
DG0 DG1 DG2 DG3 DG4 DG5 DG6
0
1 2 0 0 0 0
2. Press : DG3..DG6 flash.
DG0 DG1 DG2 DG3 DG4 DG5 DG6
0
1 2 0 0 0 0
3. Press for one second, then displays DG3..DG6 indicate the following result of the
operation:
DG0 DG1 DG2 DG3 DG4 DG5 DG6
0
1 2 0 0 0 2
STORING HAS CORRECTLY
TAKEN PLACE
Or
DG0 DG1 DG2 DG3 DG4 DG5 DG6
0
1 2 0 0 0 3
STORING INCORRECT.
Repeat the command or replace the board.
