SEA SETRONIK1 - Error Code Legend for Troubleshooting

SEA SYSTEMS
INSTALLATION AND USE MANUAL
CONTROL PANEL and PREWIRED SYSTEM STK1
For Electric and Hydraulic Lifts
MSTK12-GB
Rev.01
30/12/05
SETRONIK1 Pagina 47 di 54
4.6.ERROR CODE LEGEND
CODE DESCRIPTION
001 Run timer action ( Timer 4.00.XXXX )_Immediate Permanent Out of Order
002 Low speed timer action ( Timer 4.01.XXXX )_ Immediate Permanent Out of Order
003 Overload cut-out 1 action (-RT)_Permanent Out of Order at floor
004 Not used
005 The car has performed a number of levellings equal to the value set in Parameter
1.06.XXXX_Permanent Out of Order at floor
006 Run (KM)/ High (KA)/ Low (KB) contactors sticking_ Immediate Permanent Out of
Order
007
Up (KS)/ Star (KY)/ Delta (K∆) contactors sticking_Immediate Permanent Out of Order
008 Down (KD)/ impedance/resistors exclusion (KE) contactors sticking_ Immediate
Permanent Out of Order
009 Lack of or wrong input phases sequence_ Immediate Temporary Out of Order
010 Safety chain Terminal 1 with no voltage_ Immediate Temporary Out of Order
011 Overtravel action (Ex) _ Immediate Permanent Out of Order
012 Pit stop action (AF)/ Maintenance Stop (MA)/ Safety gear (PT)/ Approaches (ACC)/
End of Timer 4.13.XXXX at floor with doors kept open_ Immediate Permanent Out of
Order
013 Not used
014 Safety photocell action (for cars with no doors) _ Immediate Temporary Out of Order
015 Failed excitation of the Run (KM)/ High (KA)/ Low (KB) contactors
016
Failed excitation of the Up (KS)/ Star (KY)/ Delta (K∆) contactors
017 Failed excitation of the Down (KD)/ impedance exclusion (KE) contactors
018 Failed excitation of the resistors exclusion (KEA, KEB) contactors
019 Safety circuit (CS1) active with car off floor (input function 11)_ Immediate Temporary
Out of Order
020 Safety circuit (CS1) not active with car at floor (input function 11)_ Immediate
Temporary Out of Order
021..044 Failed closing of safety contacts PC \ PC1 \ BC..BCn on floor
(Floor number = ‘Error code’ less 20)
045..068 Opening of safety contacts PC \ PC1 \ BC..BCn going to the floor
(Floor number = ‘Error code’ less 44)
069 Opening of the safety contacts PC \ PC1 \ BC..BCn during resetting run
