SEA SETRONIK1 - Page 48

SEA SYSTEMS
INSTALLATION AND USE MANUAL
CONTROL PANEL and PREWIRED SYSTEM STK1
For Electric and Hydraulic Lifts
MSTK12-GB
Rev.01
30/12/05
SETRONIK1 Pagina 48 di 54
CODE DESCRIPTION
070 Failed excitation of door opening minicontactor KAP for 1°operator (if it exists)
071 Failed excitation of door opening minicontactor KAP1 for 2°operator (if it exists)
072 Failed excitation of door closing minicontactor KCP for 1° operator (if it exists)
073 Failed excitation of door closing minicontactor KCP1 for 2° operator (if it exists)
074 Sticking of door opening/closing minicontactor KAP \ KCP for 1°operator (if it exists)
075 Sticking of door opening/closing minicontactor KAP1 \ KCP1 for 2°operator (if it exists)
CODE DESCRIPTION
076 Door opening limit switch FCA did not open after the programmed time (Timer 4.04.)
(if it exists)
077 Door closing limit switch FCC did not open after the programmed time (Timer 4.04) (if
it exists)
078 Door opening limit switch FCA1 (for 2°operator) did not open after the programmed
time (Timer 4.05) (if it exists)
079 Door closing limit switch FCC1 (for 2°operator) did not open after the programmed
time (Timer 4.05) (if it exists)
080 Floating floor off for more than 5 consecutive runs (with programmed parameter 1.07)
090 Oil thermal sensor action (STO) in hydraulic lifts or Motor thermal sensor action (TS1-
TS2) in Electric lifts_ Temporary Out of Order at floor
091 Low and/or peak point pressure switch action (SP, SP1) (standard electrical
configuration)_ Immediate Permanent Out of Order
092 Alarm combined with Function 04 input_ Immediate Permanent Out of Order
093 Not used
094 Alarm combined with Function 17 input_ Temporary/Permanent Out of Order at floor
095 Alarm combined with Function 18 input_ Permanent Out of Order at floor
096 Alarm combined with Function 19 input (e.p. ACVV, VVVF, electronic valve GEV,…)_
Immediate Permanent Out of Order
097 Failed start (Combined with Function 20 input, e.p. VVVF,… )_ Permanent Out of
Order at floor
098 Alarm combined with Function 25 input_ Permanent Out of Order at floor
